型号  HT170E01-300

解析度  SXGA
整体尺寸 mm 358.5(W)X296.5(H)X17.0(D)
有效显示区域 mm 337.92(H)X270.336(V)
像素点数  1280(H)X1024(V)
像素点距 mm 0.264(H)X0.264(V)
重量 g 1900 Max.
色彩数  16.2M
驱动电压 v 5
耗电率  22.1
亮度 cd/㎡ 300 Typ.
对比率  700:1
背光源  4CCFL
视角(CR 10:1) L/R  75°/75°
75°/60°
信号界面  LVDS 2ch
响应时间 ms 8 Typ.
生产时间  Now


17inch BOE-Hydis TFT LCD, 1280x1024, HT170E01-300

Model: HT170E01-300
Resolution: SXGA
Out Dimension: 358.5(W)X296.5(H)X17.0(D)
Active area: mm 337.92(H)X270.336(V)
Resolution:  1280(H)X1024(V)
Dot Pitch: mm 0.264(H)X0.264(V)
Weight: g 1900 Max.
Color:  16.2M
Driver voltage: v 5
Power:  22.1W
Brightness cd/㎡ 300 Typ.
Contrast Ration: 700:1
Backlight:  4CCFL
Viewing Angle(CR 10:1) L/R  75°/75°75°/60°
Interface:  LVDS 2ch
Response Time ms 8 Typ.
