使用空气压(0.4)0.5~0.6MPa
| 型号 | 工作能力螺栓尺寸 | 扭矩范围N·m | 空转速度rpm | 全长 (不包括套筒或者刀头) mm | 重量 (不包括套筒或者刀头) kg | 中心到外侧距离 mm | 方头或六角头驱动尺寸 mm | 软管接头 | 推荐的软管内径 mm | 平均耗气量 m3/min | 声压大小 dB(A) | 振动 (不确定) m/s2 | 产品代码 | ||||
| 0.4~0.5/0.5~0.6MPa | 0.4/0.5/0.6MPa | ||||||||||||||||
| UAT40 | 5 | 4.5-8.0/4.5-8.0 | 3300/3600/3800 | 162 | 0.92 | 24.5 | 9.5Sp | Rc? | 6.5 | 0.20 | 75 | < 2.5 | 18A41 | ||||
| UAT50 | 6-8 | -/7.0-15.5 | -/4400/4600 | 162 | 0.92 | 24.5 | 9.5Sp | Rc? | 6.5 | 0.25 | 78 | < 2.5 | 18B21 | ||||
| UAT60 | 8 | -/15.0-32.0 | -/6300/6700 | 174 | 0.95 | 24.5 | 9.5Sp | Rc? | 8.0 | 0.35 | 80 | < 2.5 | 18C81 | ||||
| UAT70 | 8-10 | -/30.0-55.0 | -/5700/6000 | 180 | 1.05 | 25.5 | 9.5Sp | Rc? | 8.0 | 0.40 | 80 | < 2.5 | 18E31 | ||||
| UAT80 | 10-12 | -/45.0-63.0 | -/5300/5600 | 186 | 1.25 | 28 | 9.5Sp | Rc? | 8.0 | 0.48 | 80 | < 2.5 | 18F21 | ||||
| UAT90 | 10-12 | -/50.0-85.0 | -/5400/5700 | 192 | 1.45 | 29 | 12.7Sp | Rc? | 8.0 | 0.53 | 82 | < 2.5 | 18F51 | ||||
| UAT100 | 12 | -/70.0-130.0 | -/4900/5200 | 199 | 1.7 | 31.5 | 12.7Sp | Rc? | 8.0 | 0.55 | 82 | < 2.5 | 18F81 | ||||
| UAT40D | 5 | 4.5-8.0/4.5-8.0 | 3300/3600/3800 | 165 | 0.92 | 24.5 | 6.35Hex | Rc? | 6.5 | 0.2 | 75 | < 2.5 | 18A61 | ||||
| UAT50D | 6-8 | -/7.0-15.5 | -/4400/4600 | 165 | 0.92 | 24.5 | 6.35Hex | Rc? | 6.5 | 0.25 | 78 | < 2.5 | 18B51 | ||||
| UAT60D | 8 | -/15.0-32.0 | -/6300/6700 | 177 | 0.95 | 24.5 | 6.35Hex | Rc? | 8.0 | 0.35 | 80 | < 2.5 | 18D11 | ||||
| UAT50L | 6-8 | 7.0-15.5/- | 4000/4300/- | 162 | 0.92 | 24.5 | 9.5SP | Rc? | 6.5 | 0.20 | 75 | < 2.5 | 18C11 | ||||
| UAT60L | 8 | 13.0-28.0/- | 6000/6500/- | 174 | 0.95 | 24.5 | 9.5SP | Rc? | 8.0 | 0.25 | 77 | < 2.5 | 18D71 | ||||
| UAT70L | 8-10 | 25.0-48.0/- | 5300/5600/- | 180 | 1.05 | 25.5 | 9.5SP | Rc? | 8.0 | 0.30 | 78 | < 2.5 | 18E81 | ||||
| UAT80L | 10-12 | 35.0-55.0/- | 5000/5300/- | 186 | 1.25 | 28 | 9.5SP | Rc? | 8.0 | 0.40 | 78 | < 2.5 | 18F31 | ||||
| UAT90L | 10-12 | 45.0-75.0 | - | 5100 | 5600 | - | 192 | 1.45 | 29 | 12.7Sp | Rc? | 8.0 | 0.45 | 79 | < 2.5 | 18F61 | |
| UAT100L | 12 | 60.0-110.0 | - | 4800 | 5200 | - | 199 | 1.7 | 31.5 | 12.7Sp | Rc? | ☆11.0 | 0.48 | 79 | < 2.5 | 18F91 | |
| UAT50DL | 6-8 | 7.0-15.5 | - | 4000 | 4300 | - | 165 | 0.92 | 24.5 | 6.35Hex | Rc? | 6.5 | 0.20 | 75 | < 2.5 | 18B71 | |
| UAT60DL | 8 | 13.0-28.0 | - | 6000 | 6500 | - | 177 | 0.95 | 24.5 | 6.35Hex | Rc? | 8.0 | 0.25 | 77 | < 2.5 | 18D31 | |
为气压*0.6Mp（刻表）负荷时的数据。低气压L型工具为气压0.4MPa负荷时的数据，单位为（约）m3/分。转矩范围为紧固的大致标准值，型号名称带有D的类型为触摸式螺丝起子用轴，请根据实际的参数正确选用工具。
噪音等级：按照ISO15744; 噪音浮动值是3大B（A)；
振动等级：按照ISO28927-2;进气口螺纹：N.P.T.1/4”；
进气软管尺寸:10×6.5×5m用于UAT50系列 12×8.0×5m系列用于UAT100系列 16×11.0×5m用于UAT100L；
