江苏常州胜名电子有限公司:

500v 600v 700v 1000v保险丝 3000v 量大优惠 认证齐全 ce tuv rohs 出口品牌 绝非某些三无产品可以对比的

电流:500ma 5a 10a1a2a6a8a10a15a20a25a12a 30a 32a

电压:1000v ac/dc

尺寸:5*20 /6*30 /6*32 /6.3*31.5 /10*38

灭弧方式:	真空断路器	型号:	pv
额定绝缘电压:	3000(v)	极数:	1p
品牌:	swefuse	机械寿命:	10000(万次)
额定频率:	50hz(hz)	加工定制:	否

系列常用型号:

pv-15a10fc

pv-12a10fc
pv-10a10fc

pv-8a10fc

pv-6a10fc
pv-5a10fc

pv-4a10fc
pv-3a10fc
pv-2a10fc

pv-1a10fc

额定电压:	1500(v)3000v	类型:	熔断器
型号:		额定电流:	15(a)30a
品牌:	swefuse	产品认证:	ce rohs
额定分断电流:	30k(a)	加工定制:	是

catalogue numbers rated
current
(amps)
rated
voltage
(vdc)
i
2t (a2s)
watts loss
(w)
cylindrical bolt fixing
pcb fixing
single pin
pcb fixing
double pin
prearcing
total at
1000v 0.8 in
i
n
pv-1a10f pv-1a10-t pv-1a10-1p pv-1a10-2p 1
1000
0.15 0.4 0.8 1.5
pv-2a10f pv-2a10-t pv-2a10-1p pv-2a10-2p 2 1.2 3.4 0.6 1.0
pv-3a10f pv-3a10-t pv-3a10-1p pv-3a10-2p 3 4 11 0.8 1.3
pv-3-5a10f pv-3-5a10-t pv-3-5a10-1p pv-3-5a10-2p 3.5 6.6 18 0.9 1.4
pv-4a10f pv-4a10-t pv-4a10-1p pv-4a10-2p 4 9.5 26 1.0 1.5
pv-5a10f pv-5a10-t pv-5a10-1p pv-5a10-2p 5 19 50 1.0 1.6
pv-6a10f pv-6a10-t pv-6a10-1p pv-6a10-2p 6 30 90 1.1 1.8
pv-8a10f pv-8a10-t pv-8a10-1p pv-8a10-2p 8 3 32 1.2 2.1
pv-10a10f pv-10a10-t pv-10a10-1p pv-10a10-2p 10 7 70 1.2 2.3
pv-12a10f pv-12a10-t pv-12a10-1p pv-12a10-2p 12 12 120 1.5 2.7
pv-15a10f pv-15a10-t pv-15a10-1p pv-15a10-2p 15 22 220 1.7 2.9
pv-20a10f pv-20a10-t pv-20a10-1p pv-20a10-2p 20 34 350 2.1 3.632ma,63ma,100ma,150ma,200ma,250ma,300ma,400ma,500ma,600ma,800ma,1a,1.25a,1.6a,2a,2.5a,3a,3.5a,4a,5a,6a,7a,8a,9a,10a,12a,15a,20a,25a,30a1000v 保险丝 6*32 10*38 14*51 1000v保险管
产品:
江苏常州胜名电子有限公司专供
光伏电池直流熔断器专门设计为用于光电(pv)系统,主要作用是为了保护太阳能电池板。
太阳能电池板的分断条件是,在有效分断故障光电池组的同时,不影响其它正常工作的光电池组的运作。
电流范围:1a,2,3a,4a,5a,6a,7a,8a,10a,15a--30a
额定电压:1000vdc
最大分断电流: 33ka 25ka swe
产品认证: iec 60269
尺寸:10x38mm 胜名
典型保护: 太阳能光伏电池
型号: pv-8a10f pv-10a10f pv-12a10f pv-15a10f
      pv-8a10f-t pv-10a10f-t pv-12a10f-t        pv-15a10f-t pv-8a10f-1p pv-10a10f-1p
      pv-12a10f-1p pv-15a10f-1p pv-8a10f-2p
      pv-10a10f-2p pv-12a10f-2p pv-15a10f-2p
大量现货。
